ZONESUN ZS-CYXR12 Automatic Hot Melt Glue Film Round Bottle Labeling Machine

DESCRIPTION

This series of labeling machines has a wide range of applications. It is suitable for circular labeling of various materials including OPP film, pearlescent films, paper-plastic composite films, and paper labels on round and other cylindrical containers such as plastic bottles, glass bottles, and metal cans.

Whatever your packaging needs are, you can rely on ZONESUN.

PARAMETER

• Model：ZS-CYXR12
• Power Supply：3-phase 380V, 50Hz, 11kW
• Working Speed：12,000 bottles/hour (this model can customize 12,000/15,000/20,000/24,000 BPH)
• Labeling Accuracy：±1mm
• Required Size of Labels：15–1500mm
• Required Size of Label Rolls：Inner Diameter: 152mm / Outer Diameter: <500mm
• Applicable Bottles：Diameter: 30–86mm / Height: 70–360mm
• Gluing Temperature：120–160°C
• Machine Size：(L)3300mm × (W)1400mm × (H)2100mm

PLC CONTROLLER

Present all parameters and settings in a clear and concise manner, making it easy for the user to operate.

LABELING MODULE

Adopting advanced labeling technology, glue is only applied to both ends of the label, eco-friendly and cost-saving.

ROTARY BOTTLE HOLDER

Customizable based on various bottle size, suitable for different production needs.

STAINLESS STEEL COVER

The use of oxidation, plastic spraying, painting, and other processes to prevent corrosive pollution, easier to clean and maintain.
