DESCRRIPTION
- Model：ZS-CTF50
- Power Supply：380V, 50Hz
- Mold Size：291.5 × 291.5 × 11.3 mm
- Cavity Size：15.5 × 15.5 × 10 mm
- Cavity Volume：2.4 ml (Gummy:3.2 g, Chocolate:2.8 g)
- Pistons：10 pcs, adjustable & removable nozzles
- Depositing Speed：30–60 shots/min
- Depositing Weight：1–4.5 g/shot
- Hopper Capacity：12 L
- Material：Stainless Steel 304
- Max Nozzle Heat：130°C (extra part required)
- Cooking Pot Capacity：20 L
- Heating Tubes：2 × 3 kW
- Stirring Motor：0.37/0.55 kW
- Heating Power：6.5 kW / 380V
- Heat Transfer Oil System：With oil level gauge & filling port
Smart Control Screen
Intuitive touchscreen interface simplifies operation, allowing users to easily monitor and adjust settings.
Filling Nozzles
Dispenses gummy candy precisely into molds with 10 removable nozzles, easily adjusted or replaced for flexible production of candies in various shapes and sizes.
Filling Head
Transfers syrup from the boiling and stirring pot into the hopper, ensuring smooth flow and accurate feeding for the depositing process.
Boil Stirring Pot
Efficiently dissolves, cooks and mixes ingredients, ensuring even heating and consistent syrup texture.
Conveyor Belt
Moves mold trays row by row beneath the filling nozzles, ensuring accurate positioning for syrup depositing during gummy candy production.
Motor
Drives the agitator inside the boiling pot, ensuring continuous mixing, even heating, and consistent syrup texture during gummy candy preparation.
