ZONESUN ZS-MS1 Metal Detection Machine Separator

Ensure product purity with the ZS-MS1 Metal Detection Separator. Designed to remove magnetic and non-magnetic particles as small as 0.3mm, it protects your materials with precision. The Quick Flap System reduces waste while maintaining high throughput. Built from 304 stainless steel, it’s ideal for industrial environments demanding uncompromising quality and safety.

Parameter

• Model: ZS-MS1

• Power Supply: 220V, 50/60Hz

• Input Current: 80/160 mA

• Fuse: 2 × 315 mA

• Ambient Temperature: -10°C to 60°C

• Compressed Air: 4–8 bar

• Air Consumption: 0.4 L (per separation action)

• Separation Time: 0.2–2.5 sec

• Housing Material: SUS304 stainless steel

• Adjustable Detection Accuracy: Level 0–10

• Hose Connection: 8 mm

• Channel Diameter: 50 mm

• Processing Capacity: 800 kg/hr
• Sensitivity: PE: 0.5 / Cu: 0.7 / SUS: 1.2
• Machine Body Separation Switch Material: 5 mm SUS304 stainless steel
  Machine Dimensions: 600 × 500 × 150 mm (L × W × H)
