DESCRIPTION

Equipped with piston pumps, this machine is suitable for filling thin and thick liquid like shampoo, engine oil, laundry detergent, and jam. It is a modular design with a filler and a conveyor. And customization is available.

Parameter

• Machine Model: ZS-DTYT2
• Voltage: 220V/110V 50-60Hz
• Power: 130W
• Filling Range: 10-100 / 10-200 / 30-300 / 50-500 / 100-1000 / 250-1000 / 500-5000ml
• Filling Speed: About 20 bottles/min (based on 450ml water)
• Applicable Bottle Diameter: About 53-100mm
• Filling Accuracy: ≤ ±1%
• Conveyor Belt Size: 1020 × 140mm (L × W)
• Machine Size: 1020 × 160 × 870mm (L × W × H)

PRODUCT DETAILS

CONTROL PANEL

FILLING

Pneumatic, powerful, diving nozzles.

ADJUSTMENT

Filling speed and interval time.

PHOTOELECTRIC EYE

Optical fiber sensing, smart and efficient, auto-detecting.

CONVEYOR

With a high-quality conveyor belt, it can transport bottles steadily. The conveying speed and width of it can be adjusted.
