ZONESUN ZS-GFGT520 Full Automatic Paste Satchet Bag Filling Sealing Machine With Feeding Pump
ZONESUN ZS-GFGT520 Full Automatic Paste Satchet Bag Filling Sealing Machine With Feeding Pump
Regular price
$14,199.00 USD
Regular price
Sale price
$14,199.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
DESCRIPTION
This machine is designed for filling and back side sealing paste.The filling volume and speed can be adjusted according to operation needs.And we can customize the sealing method according to operation needs.It is widely used in food,beverage and chemical industries.
Parameter Details
Model ZS-GFGT520
Power Supply 220V / 50Hz / 4kW
Filling Pump Type Piston Pump
Filling Range 100–1000 ml (customizable)
Packaging Speed Approx. 5–50 bags/min<br>(depends on material & bag size)
Sealing Method Back seal / 3-side seal / 4-side seal
Bag Size Width: 130–300 mm<br>Length: up to 400 mm
Film Width Max 520 mm
Film Material OPP/CPP, OPP/PE, NILO/PE, PE
Air Pressure 0.65 MPa
Air Consumption 0.8 m³/min
Machine Dimensions Approx. 1880 × 1370 × 1800 mm (L×W×H)
Machine Weight Approx. 600 kg
Power Supply 220V / 50Hz / 4kW
Filling Pump Type Piston Pump
Filling Range 100–1000 ml (customizable)
Packaging Speed Approx. 5–50 bags/min<br>(depends on material & bag size)
Sealing Method Back seal / 3-side seal / 4-side seal
Bag Size Width: 130–300 mm<br>Length: up to 400 mm
Film Width Max 520 mm
Film Material OPP/CPP, OPP/PE, NILO/PE, PE
Air Pressure 0.65 MPa
Air Consumption 0.8 m³/min
Machine Dimensions Approx. 1880 × 1370 × 1800 mm (L×W×H)
Machine Weight Approx. 600 kg
