DESCRIPTION

With intelligent sensors, this machine can automatically fill liquid and stop when the bottle is full. It can fill 375ml red wine in 5 seconds. It is widely used in food and beverages industries. We have an entire solution for automated production line.

APPLICATION

This machine is suitable for filling liquid such as wine, Baijiu, Beer etc.

⚠️ Important Notice for 110V Machines

110V machines must be connected to an external voltage converter before operation. Please make sure the voltage converter is properly connected after receiving the machine.

Failure to use the external voltage converter may cause excessive power load and could burn out electrical components or the control system of the machine.

PARAMETER

• Product Model：ZS‑RWGFP4

• Rated Power：0.37 kW (with pump)

• Machine Weight：35 kg

• Production Capacity：500 – 1000 bottles/hour

• Bottle Height：160 – 350 mm

• Bottle Body Diameter：60 – 100 mm

• Bottle Opening Inner diameter：> 16 mm

• Machine Size：710 × 440 × 1250 mm

• Net Weight：45 kg

• Package Size Approx.：710 × 580 × 1160 mm

• Package Weight Approx.：63 kg

PRODUCT DETAILS

FILLING HEAD

Four-head design, stainless steel casing, stable and durable. High working efficiency, high precision and anti-dripping system.

PUMP

370W, 2860r/min, max flow rate: 2.73m3/h, heat-resistant and durable.

ADJUSTABLE TRAY

The thickened and height-adjustable stainless-steel tray is suitable for bottles in different heights.

WATER LEVEL

Easy to see the water level in the tank, with 2 level sensors.
