PERFUME BOTTLE CAPPING SOLUTIONS

Perfume Capping Machines for Crimp Pumps and Spray Bottles

ZONESUN supplies manual, pneumatic and automatic perfume capping machines for crimping spray pumps onto perfume bottles, sample bottles, pocket perfume bottles and cosmetic fragrance containers.

Different capping heads and positioning components can be configured according to the bottle neck, pump diameter, collar size, bottle dimensions and required production output.

01

Pump & Cap Type

Crimp pump, spray pump or decorative collar

02

Crimp Diameter

Common sizes include 13, 15, 18 and 20 mm

03

Bottle Dimensions

Bottle height, width, neck and shoulder shape

04

Automation Level

Manual, pneumatic, automatic or monoblock

05

Required Output

Small batch, medium output or automatic production

Not Sure Which Perfume Capping Machine Fits Your Bottle?

Send us photos and dimensions of your bottle, spray pump, crimp neck and decorative collar. Our team will recommend a suitable capping head and machine configuration.

Get a Machine Recommendation
Information required: Bottle Photos Bottle Dimensions Pump Diameter Collar Dimensions Required Output

PERFUME CAPPING PROCESS

How Does Perfume Bottle Capping Work?

A perfume capping machine secures the aluminum spray-pump ferrule around the bottle neck through controlled crimping. Decorative collars may require an additional pressing process.

01

Position the Bottle

Place or feed the perfume bottle into the capping position.

02

Insert the Spray Pump

Position the spray pump and dip tube correctly on the bottle.

03

Crimp the Pump

The capping head contracts around the aluminum ferrule.

04

Press the Collar

A decorative collar can be positioned and pressed when required.

05

Inspect the Closure

Check pump security, appearance and spray-pump operation.

MACHINE SELECTION GUIDE

Choose the Right Perfume Capping Machine

Select the equipment according to your production volume, bottle consistency, operator requirements and automation level.

Machine Type Recommended Use Operation Important Considerations
Manual Capping Machine Laboratory, testing and very small production batches The operator positions and crimps each bottle manually Low investment but depends more on operator consistency
Pneumatic Capping Machine Small and medium-batch perfume production Bottle placement is manual and crimping is air-powered Requires a suitable air compressor and stable air pressure
Automatic Capping Machine Continuous production with higher output requirements Bottles are conveyed, positioned and automatically capped Bottle, pump and collar samples are required for configuration
Filling & Capping Monoblock Integrated perfume filling, pump insertion and capping Multiple packaging processes are combined in one machine Filling volume, pump feeding and bottle positioning must match

Actual working output depends on bottle feeding, pump placement, operator speed, closure structure and machine configuration.

CAPPING HEAD SELECTION

Confirm the Pump, Bottle Neck and Collar Dimensions

The crimping head must match the aluminum pump ferrule. The bottle neck, shoulder and decorative collar must also provide enough positioning and pressing space.

Common Reference Sizes 13 mm · 15 mm · 18 mm · 20 mm

These are common reference sizes only. The final capping head must be confirmed using the actual spray pump and bottle samples.

01

Pump Ferrule Diameter

Measure the aluminum ferrule that will be crimped.

02

Bottle Neck Size

Confirm the bottle neck diameter and neck height.

03

Bottle Dimensions

Provide total height, width and shoulder shape.

04

Decorative Collar

Provide inner diameter, outer diameter and collar height.

05

Dip Tube Length

Confirm the tube length and whether trimming is required.

06

Finished Appearance

Confirm the required crimping finish and collar position.

MACHINE SELECTION INFORMATION

What Information Do We Need?

Send us the following information so our team can confirm the capping head, bottle positioning components and suitable automation level.

Samples are strongly recommended. Actual bottles, spray pumps and decorative collars help confirm the crimping dimensions and finished closure quality.
01

Bottle photos from multiple angles

02

Bottle height, width and neck dimensions

03

Spray-pump photos and specifications

04

Aluminum ferrule crimping diameter

05

Decorative collar dimensions

06

Required bottles per minute

07

Manual, pneumatic or automatic operation

08

Local voltage and available air supply

OPTIONAL CONFIGURATIONS

Configure the Machine for Your Perfume Packaging Process

Optional components should be confirmed before manufacturing because they may affect the machine layout, tooling and controls.

Customized Capping Head Bottle Positioning Fixture Decorative Collar Pressing Pump Feeding System Dip-Tube Trimming Automatic Bottle Feeding Conveyor Integration No-Bottle Detection PLC Touchscreen Production Counting Filling Integration Labeling Integration

SAMPLE TESTING PROCESS

Confirm the Capping Result Before Production

Sample testing can be arranged when required to confirm bottle positioning, capping-head size, crimping appearance and pump security.

01

Submit Product Details

Provide bottle, spray-pump and collar information.

02

Confirm Capping Head

Select the capping-head size according to actual samples.

03

Test Crimping

Test pump security, appearance and bottle positioning.

04

Confirm Configuration

Finalize the machine, tooling and optional functions.

FREQUENTLY ASKED QUESTIONS

Perfume Capping Machine FAQs

Common questions about spray pumps, crimping heads, decorative collars and customized perfume capping machines.

How do I select the correct perfume capping head?

The capping head should match the actual aluminum pump ferrule. Please provide the pump specification or send samples for confirmation.

Can one machine cap different pump sizes?

Different pump diameters usually require matching capping heads. Additional positioning parts may also be required for different bottles.

What is the difference between pneumatic and automatic machines?

Pneumatic machines normally require manual bottle and pump positioning. Automatic machines use conveyors and positioning mechanisms for continuous production.

Can the machine press a decorative perfume collar?

A collar-pressing device may be configured depending on the collar structure, bottle shape and selected machine model.

Can perfume filling and capping be combined?

Filling, pump insertion and capping can be integrated into a monoblock or connected production line according to the project.

Can we send bottles and pumps for testing?

Sample testing can be arranged when required. Please contact ZONESUN before sending bottles, spray pumps or decorative collars.

CUSTOM PERFUME CAPPING SOLUTION

Find a Capping Machine for Your Perfume Bottle

Send us your bottle, spray-pump and collar dimensions. Our team will recommend a suitable machine and capping head.

Get a Machine Recommendation
