Integrated Filling & Closing Systems

Monoblock Filling & Capping Machines

Combine container feeding, filling, plug insertion, cap placement and closing within one synchronized machine. ZONESUN monoblock systems are designed for compact production layouts and can be configured around your liquid, container, closure and required production capacity.

Liquid Filling & Capping Plug & Cap Insertion Perfume & Essential Oil Vials & Dropper Bottles Spray Bottles Spout Pouches

What Should You Provide?

01
Product Material Flowability, viscosity and fill volume
02
Container Details Bottle or pouch shape and dimensions
03
Closure System Plug, dropper, pump, spray or screw cap
04
Required Output Containers per minute or per hour
Integrated Packaging Automation

Why Choose a Monoblock Filling and Capping Machine?

A monoblock machine combines multiple packaging operations within one synchronized system. Depending on the application, it can integrate bottle feeding, filling, plug insertion, cap placement, capping, crimping or finished-container discharge while reducing the transfer distance between individual processes.

01

Multiple Processes in One Machine

Filling, plug insertion, cap feeding and closing can be integrated according to the container and closure structure.

02

Compact Production Layout

The integrated structure can reduce conveyor length and is suitable for factories with limited production space.

03

Synchronized Container Transfer

Rotary platforms, indexing mechanisms or star wheels help move containers accurately between working stations.

04

Application-Based Configuration

Pumps, filling nozzles, cap feeders and closing heads can be selected around the actual product and packaging sample.

Typical Working Process

From Container Feeding to Finished Packaging

The exact working sequence depends on the machine model. Optional stations may be added, removed or customized according to your bottle, product, inner plug and outer cap.

01 Container Feeding Manual loading or automatic container feeding
02 Product Filling Metered filling based on product characteristics
03 Plug Insertion Optional dropper, stopper or inner-plug placement
04 Cap Closing Screw capping, pressing, crimping or custom closing
05 Product Discharge Transfer to labeling, coding or inspection equipment
Equipment Comparison

Monoblock Machine or Inline Packaging Line?

Both configurations can automate filling and closing. The more suitable structure depends on your container, production capacity, available floor space and future expansion requirements.

Monoblock System

Compact Integrated Configuration

  • Multiple operations mounted on one machine base
  • Shorter container-transfer distance
  • Suitable for small bottles and precision packaging
  • Compact factory layout
  • Configuration usually follows a defined package range
Inline System

Modular Production-Line Configuration

  • Separate machines connected by conveyors
  • More flexible station arrangement
  • Easier to expand or replace individual machines
  • Suitable for wider packaging-line layouts
  • Requires more floor space and line coordination
Common Applications

Containers and Products for Monoblock Packaging

01
Perfume Bottles Filling, pump insertion and crimping
02
Essential Oil Bottles Filling, inner plug and screw capping
03
Dropper Bottles Liquid filling and dropper-cap assembly
04
Vials and Small Bottles Controlled filling and closure installation
05
Spray Bottles Filling, spray-pump feeding and closing
06
Spout Pouches Liquid filling and spout-cap tightening
07
Cosmetic Creams Paste filling and cap placement
08
Reed Diffusers Filling, plug insertion and capping
09
Special Containers Customized holders and closing mechanisms
Machine Selection

Information Needed for Configuration

Monoblock machines are closely matched to the product, container and closure. Providing complete samples and production information helps determine the correct filling and closing configuration.

01
Product & Filling Volume Flowability, viscosity and target dosage
02
Container Samples Shape, material, opening and dimensions
03
Plug and Cap Samples Closure structure and installation method
04
Required Capacity Containers per minute or per hour
05
Production Environment Voltage, air supply and factory conditions
06
Additional Processes Labeling, coding, inspection or conveying
Frequently Asked Questions

Monoblock Machine FAQ

What is a monoblock filling and capping machine?
A monoblock machine combines two or more packaging operations on one machine base. A typical configuration may include filling, inner-plug insertion, cap placement and capping or crimping. Actual working stations vary according to the container and closure.
What is the difference between a monoblock machine and a complete production line?
A monoblock machine concentrates several operations within one integrated unit. A complete production line normally connects multiple independent machines through conveyors and may include container sorting, cleaning, filling, capping, labeling, coding, inspection and secondary packaging.
Can one monoblock machine handle different bottle sizes?
Many models can handle a defined range of containers through adjustment or change parts. Significant differences in bottle shape, opening, plug or cap structure may require customized holders, star wheels, guides, filling nozzles or capping heads.
Which filling system can be used in a monoblock machine?
Depending on the product, the machine may use peristaltic, magnetic, piston, ceramic, diaphragm or rotor-pump filling. Product viscosity, filling volume, accuracy requirements and cleaning needs should be confirmed before pump selection.
Can labeling or coding be integrated into the machine?
Some projects can integrate coding, inspection or labeling functions, while others are better connected to separate downstream equipment. The final structure depends on available space, output and packaging complexity.
Are bottle and cap samples required before production?
Physical samples are strongly recommended for confirming machine holders, plug insertion, cap feeding, capping torque and container transfer. Changes to the container or closure after confirmation may affect the machine configuration.

Configure a Monoblock Machine for Your Package

Send your product, container, plug, cap and production-capacity details for an application-based machine recommendation.
